Part Number:

OMM12.5-151G0001, OMM12.5151G0001, 151G0001, OMM125151G0001, BMM-12.5-M-A-IE, BMM12.5MAIE, BMM125MAIE

Specification:

Cylindrical output shaft 16mm with 3/8 BSP end ports

OMM 12.5 Low Speed High Torque motor, Geometric Displacement 12.9 cm
Motor Size: 12.5

Geometric displacement: 12.5cm/[0.77in]
Max speed cont: 1550 rpm

Max speed int: 1940 rpm

Max torque cont: 16Nm/[140lbf in]

Max torque int: 23Nm/[200lbf in]

Max output power cont: 2.4kW/[3.2hp]

Max output power int: 3.2kW/[4.3hp]

Max pressure drop cont: 100bar/[1450psi]

Max pressure drop int: 140bar/[2030psi]

Max pressure drop peak: 200bar[2900psi]

Max oil flow cont: 20L/min

Max oil flow int: 25L/min

Max starting pressure with unloaded

Shaft: 4bar/[60psi]

Min starting torque at max press drop cont: 12Nm/[105lbf in]

Min starting torque at max press drop int: 17Nm/[150lbf in]

Max inlet pressure cont: 140bar/[2030psi]

Max inlet pressure int: 175bar/[2540psi]

Max inlet pressure peak: 225bar/[3260psi]

Max return pressure with drain line cont: 140bar/[2030psi]

Max return pressure with drain line int: 175bar/[2540psi]

Max return pressure with drain line peak: 225bar/[3260psi]

Application:

Fit for Danfoss
